XDS Advance 300 vs NCM M3

One e-bike can look perfect online and feel wrong as soon as you stop at the first set of lights. Size is often the reason. This XDS Advance 300 vs NCM M3 guide starts with rider fit, then looks at battery, range, weight, brakes and trail use.

The XDS Advance 300 vs NCM M3 Electric Bike choice is quite simple. The 24-inch XDS is made for shorter riders. The NCM M3 comes in larger sizes and offers more battery capacity for longer rides.

Choose the XDS if the rider is around 130- 155 cm tall and wants a compact bike. Choose the NCM M3 if the rider is an adult who wants larger wheels, a removable battery and a longer claimed range. Both Australian versions use a 250W hub motor and stop electric assistance at 25km/h.

XDS Advance 300 vs NCM M3 Comparison at a Glance

Start With Rider Size, Not Motor Power

This is the biggest difference between the two bikes. The XDS has 24-inch wheels and a 12-inch frame. E-Ozzie recommends it for riders from 130cm to 155cm tall. That smaller setup can make starting, stopping and changing direction feel easier for a shorter rider.

The NCM starts with a 26-inch model. Its Australian size chart recommends that version for riders from 160cm to 185cm. There are also 27.5 and 29-inch choices for taller riders.

A rider should be able to stand over the bike, reach the brakes without stretching, and put a foot down with confidence. If the frame is too large, the bigger battery will not make the bike safer or nicer to ride.

Size winner: XDS for riders within the 130-155cm range. NCM M3 for most adult riders.

E-Bike Motor and Battery Comparison

Both bikes have a 250W hub motor in their Australian setup. Both also stop motor assistance at 25km/h.

The XDS uses a 36V system. The battery is rated at 12.8Ah, which works out to about 460.8Wh. That figure is calculated from voltage multiplied by amp-hours.

The NCM uses a 48V 12Ah battery with 576Wh of stored energy. On paper, that is 25% more battery capacity than the XDS.

The NCM battery is also removable. You can take it inside for charging instead of moving the whole bike near a power point. The XDS battery is integrated into the frame, but the current product page does not clearly state how it is removed for charging.

Battery winner: NCM M3.

How Far Can Each Bike Go?

E-Ozzie lists a range of 40- 80 km in ECO mode for the XDS Advance Electric Bike. The NCM M3 is advertised at up to 110km.

These are maximum claims, not promises. Hills, rider weight, headwinds, cold weather, tyre pressure and assist level all change the result. Soft dirt also uses more battery than a smooth bike path.
Range winner: NCM M3 on the published figures.

Which Bike Feels Better on Paths and Trails?

The 24-inch XDS should feel more compact and quick to steer. Smaller wheels can be easier for a young or short rider to manage at low speed. Its 100mm lockout fork helps soften bumps, while the 24 x 2.1 tyres suit paths, gravel and light trails.

The NCM M3 Electric Mountain Bike has larger wheels and wider tyres. Larger wheels usually roll over small holes and rough sections more easily. The Suntour XCT fork adds front suspension, while the larger frame options give adults a more natural riding position.

Trail winner: XDS for compact control. NCM M3 for adult sizing and easier rollover on rough ground.

Gears and Brakes

The XDS has a Shimano CUES 9-speed setup with one front chainring. This is simple to use because there is only one gear control. The 11-36T rear range gives the rider useful choices for flats and hills without a front derailleur to manage.

The Australian 2025 NCM M3 uses a Shimano Altus triple front chainring and a 7-speed rear system. That gives more gear combinations. It may suit riders who like to fine-tune their pedalling, but it also adds a second shifter and more parts to adjust.

Gearing winner: XDS for simplicity. NCM M3 for the number of gear combinations.

Brake result: Even on the current listed versions.

Weight and Everyday Handling

The NCM M3 is listed at 25kg. E-Ozzie lists the XDS at 30, which the supplied product details identify as kilograms. That makes the NCM about 5kg lighter on the published numbers.

Five kilos is noticeable when lifting a bike onto a rack or pushing it up steps. The smaller XDS may feel easier for a short rider while moving, but that does not automatically make it easier to lift.

The NCM also includes a front light powered by the bike. The XDS specifications list a bell and kickstand but do not list an integrated light.

Everyday winner: NCM M3 for lower listed weight, a removable battery and the included front light.

Benefits and Limits Comparison

Test Ride Before You Decide

E-Ozzie offers free test rides at its Melbourne, Sydney and Perth showrooms. No appointment is needed, but it is smart to call first and check stock because model availability changes.

• Melbourne: 22a/42 McArthur's Road, Altona North VIC 3025

• Sydney: 91B Princes Hwy, St. Peters NSW 2044

• Perth: 580 Beaufort Street, Mount Lawley WA 6050



E-Ozzie also offers servicing and repairs at these locations, plus phone and video-call support. The store states that its e-bikes come with up to six months of free service; confirm the inclusions for the exact model. The XDS Advance 300 vs NCM M3 decision is easier when the rider can sit on the bike, test the brakes and ride at low speed before buying.

FAQs

Which bike is better for a shorter rider?

The XDS is the clearer choice for a rider from 130cm to 155cm. Its 24-inch wheels and 12-inch frame are much smaller than the NCM M3 options. A test ride is still important.

Which bike has the longer range?

The NCM M3 has the longer advertised range at up to 110km. The XDS is listed at 40- 80 km in ECO mode. Actual distance will change with hills, rider weight, weather and assist level.

Do both bikes have removable batteries?

The NCM M3 battery is listed as integrated and removable. The XDS battery is integrated, but the current XDS and E-Ozzie pages do not clearly explain customer removal. Ask the store to show you how charging works.

Are both bikes suitable for mountain trails?

They suit gravel, park paths and light trails. Both are hardtails with front suspension only. For rocky descents, jumps or hard downhill riding, look for a bike designed for that use.

Do both bikes have hydraulic brakes?

Yes, based on the current Australian listings used here. The XDS has 160mm hydraulic discs. The Australian 2025 NCM M3 lists Das-Kit hydraulic discs. Check the exact M3 version because older pages show different brakes.

Which bike is easier to carry?

The NCM M3 should be easier on the published figures because it weighs 25kg, compared with the XDS listing of 30kg. Remove the NCM battery before lifting when the manual allows it, and check that your bike rack can carry the bike's weight.
